| Isuzu Engineering Truck | ||||
| NO. | SPECIFICATION | PARAMETER | ||
| 4×2 | 4×4 | |||
| 1 | Model Series | KV100 | T17 | TAGA H |
| 2 | Vehicle Model | QL5040XGCBUHAJ | QL5032XGCCZHWJ | QL5031XGCCTHWJ |
| 3 | GVW(kg) | 4495 | 2520 | 2990 |
| 4 | Curb Weight(kg) | 3300 | 1995 | 2275 |
| 5 | Axle Loads(kg) | 1750/2745 | 1150/1370 | 1350/1640 |
| 6 | Cabin | 6-9 | 2+3 | 2+3 |
| 7 | Overall Dimension(mm) | 5995×2010×2610,2870 | 5524×1690×1875 | 5638,5523×1990×2350 |
| 8 | Wheelbase(mm) | 3360 | 3379 | 3406 |
| 9 | Engine | 4KH1CN6LB/4KB1-TCG60 | 4KH1CT6H1 | 4KH1CT6S1 |
| 10 | Engine Output (kW(PS)) | 88kW(120PS)/96kW(130PS) | 105kW(143PS) | 110kW(150PS) |
| 11 | Displacement(L) | 2.999/2.499 | 2.999 | 2.999 |
| 12 | Emission Standard | Euro 6 | ||
| 13 | Braking Mode | Oil Brake/Air Brake | ||
| 14 | Max Speed(km/h) | 105, 115 | 145 | 140 |
| 15 | Front/Rear Overhang(mm) | 1110/1525 | 839/1306 | 977/1255,977/1140,1074/1145,977/1145 |
| 16 | Tire Model | 7.00R16LT 8PR | 215/75R15,235/75R15LT | 265/65R18,265/60R18 |
| 17 | Product Description | Reliable construction vehicles for diverse engineering and infrastructure projects, customizable and high performance. | ||
*More parameters can be customised, please contact us for more information.
